Product Details
Palisade is manufactured in both the standard ‘D’ and ‘W’ profile in a variety of thicknesses. All are available with triple-pointed & splayed, rounded & notched, rounded and pointed tops. Panels are normally supplied loose for assembly on site in bays of 2.75m. Bays can be supplied to site pre-assembled; a fully welded option is also available.
Palisade provides a physical and visible deterrent against intruders. The versatile design can accommodate all site requirements which may include bespoke hole positions, three rails, extensions for barbed wire and extended pales for burying in the ground or concrete sills. Palisade can be powder-coated in virtually any colour.
Triple pointed, single pointed, splayed and rounded or notched and rounded all available.
Specification Chart
| Height | Post length | Rail size | Pale length | |
|---|---|---|---|---|
| 1000mm | 1450mm | 40x40mm | 950mm | Available to order |
| 1200mm | 1650mm | 40x40mm | 1150mm | Available to order |
| 1500mm | 1450mm | 40x40mm | 1450mm | Available to order |
| 1800mm | 2325mm | 45x45mm | 1750mm | Stock |
| 2000mm | 2590mm | 45x45mm | 1950mm | Stock |
| 2100mm | 2725mm | 45x45mm | 2050mm | Available to order |
| 2400mm | 3125mm | 50x50mm | 2350mm | Stock |
| 2750mm | 3500mm | 50x50mm | 27mm | Available to order |
| 3000mm | 3925mm | 50x50mm | 2950mm | Available to order |
| 3600mm | 4725mm | 50x50mm | 3550mm | Available to order |
Pale thickness specification
| General | Industrial | Security | |
|---|---|---|---|
| ‘W’ profile | 2.0mm | 2.5mm | 3.0mm |
| ‘D’ profile | 3.0mm | 3.5mm | 4.0mm |
Download Datasheet here
